Humboldt's NEW Electrical Density Gauge

The EDG is a non-nuclear alternative for determining the moisture and density of compacted soils used in road beds and foundations. The EDG is a portable, battery-powered instrument capable of being used anywhere without the concerns and regulations associated with nuclear safety. Its step-by-step menu guides the user through each step of the testing procedure and cautions when values do not correspond to established curves for the material being tested.

Easy-to-use, the EDG can be used as a construction aid to monitor day-to-day compaction operations by providing performance and measurement results highly comparable to those achieved with traditional methods, including the nuclear gauge. When conducting a test, the EDG measures and displays the results for wet and dry density, gravimetric moisture content and percent compaction.

The EDG measures the electrical dielectric properties and moisture levels of compacted soil using high radio frequency traveling between darts driven into the soil being tested. The dart's depth of penetration positively determines the depth of measurement.

Advantages to the Contractor

• No requirement for a highly-trained or licensed technician
• No special handling requirements for shipping or regulatory compliance for hazardous materials
• Easy to learn and easy to use with its step-by-step menu
• Lightweight and easily transportable
• Accurate and repeatable with results that mirror known testing methods

EDG Software Features

• Communicate with all your EDG gauges
• Download job and soil model data
• Create customized reports from data
• Upload soil models to any EDG
• Input proctor data for use in job data or soil model data
• View maps of test locations, using Google Earth
• Time/Date, GPS stamps provided for each test

More information on Humboldt's NEW Electrical Density Gauge and EDG Software

EDG Data Sheet (PDF)
