Los Angeles Abrasion Machine

Los Angeles Abrasion Machine

Product Options

  Part Number & Name Price QTY
Los Angeles Abrasion Machine LA Abrasion Machine, 120V 60HzH-3860D
Los Angeles Abrasion Machine LA Abrasion Machine, 120V 60Hz
$6,880.00
Los Angeles Abrasion Machine LA Abrasion Machine, 220V 60HzH-3860D.2F
Los Angeles Abrasion Machine LA Abrasion Machine, 220V 60Hz
$6,940.00
Los Angeles Abrasion Machine LA Abrasion Machine, 220V 50HzH-3860D.5F
Los Angeles Abrasion Machine LA Abrasion Machine, 220V 50Hz
$6,900.00
Add to Cart

Los Angeles Abrasion Machine

The Los Angeles abrasion machine is used to measure the degradation of mineral aggregate of standard gradings resulting from a combination of actions including abrasion or attrition, impact and grinding in a rotating steel drum containing a specified number of steel spheres. The test is widely used as an indicator of the relative quality of various sources of aggregate having similar mineral compositions.
Humboldt's design follows the ASTM-preferred design and features a welded, structural-steel frame, fabricated .5"-thick (913mm) abrasion-resistant steel drum, a removable shelf, bolted to the drum and a balanced drum assembly for easy rotation by hand. The enclosed chain drive rotates the drum without a conventional slip clutch. This positive drive delivers greater accuracy. The self-contained worm-drive motorized speed reducer has anti-friction bearings and sealed lubrication. The 1hp, electronically-controlled motor is equipped large, push-button controls and an automatic overload cutout. Unit Includes user-configured, revolution counter, a material catch pan and one abrasion charge consisting of 12 hardened-steel balls. Dimensions: 39" x 29" x 37" (991 x 737 x 940mm).

The Los Angeles Abrasion Machine supports the following standards: ASTM C131ASTM C535, AASHTO T96

Accessories

  Part Number & Name Price QTY
Abrasion Charge H-3865
Abrasion Charge
$220.00
Materials Catch Pan for LA Abrasion Machine H-3860.19
Materials Catch Pan for LA Abrasion Machine
$136.00
Sound Enclosure For LA Abrasion Machine H-3860.100
Sound Enclosure For LA Abrasion Machine
$3,200.00
Add to Cart

Literature

Manuals, Data Sheets & Safety Data Sheets
H-3860D man 0816 (Product Manual PDF)

Standards

Standards
ASTM C131
ASTM C535
AASHTO T96
