MiniSplitter Sample Splitter
The smallest of the bench-top units is all stainless steel except for aluminum chute bars and pans. Can be used to split powders to .25" (6.4mm) aggregate. The 104 in.3 (1.7L) hopper has a .375" (9.5mm) bottom opening with a spring-loaded gate release. Includes 2 pans.
Hopper Capacity: 104 in3 (1.7L)
Chute Bar Width: .125" (3mm)
Chute Bar Amount: 48
Chute Slope: 60°
Dimensions: 9.5" x 8.5" x 13.5" (214 x 216 x 343mm)
Number of Chutes (openings)
Number of Chutes (openings) |
Model | Chute Width - inches | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
.125 | .25 | .375 | .5 | .75 | 1 | 1.5 | 2 | 3 | 4 | 6 | ||
H-4291 | 48 | 24 | 16 | 12 | 8 | 6 | 4 | - | - | - | - | |
H-4290 | - | 48 | - | 24 | 16 | 12 | 8 | 6 | 4 | - | - | |
H-4289 | - | - | - | 36 | - | 18 | 12 | - | - | - | - | |
H-4288 | - | - | - | 48 | - | 24 | 16 | 12 | 8 | 6 | 4 | |
H-4293 | - | - | - | 48 | - | 24 | 16 | 12 | 8 | 6 | 4 |
Hopper Capacity in3/ft3 (liters) |
Chute Bar Width |
Chute Bar Amount |
Chute Slope |
Dimensions L x W x H inches (mm) |
Gilson # |
Model | Pans Replacements |
---|---|---|---|---|---|---|---|
104 in3 (1.7) | .125" (3mm) | 48 | 60° | 9.5 x 8.5 x 13.5 (214 x 216 x 343) | SP-3 | H-4291 | H-4291.1 |
.28 ft3 (7.9) | .25" (6mm) | 48 | 60° | 15.5 x 12.5 x 17.5 (394 x 318 x 445) | SP-2.5 | H-4290 | H-4290.1 |
0.55 ft3 (15.6) | .5" (13mm) | 36 | 45° | 22 x 14.5 x 20.5 (559 x 368 x 521) | SP-2 | H-4289 | H-4289.1 |
1.0 ft3 (28.3) | .5" (13mm) | 48 | 45° | 29 x 19 x 39 (737 x 483 x 991) | SP-1 | H-4288 | H-4288.2 |
1.0 ft3 (28.3) | .5" (13mm) | 10 Fixed | 60° | 29 x 19 x 39 (737 x 483 x 991) | SP-1C | H-4288FC | H-4288.2 |
1.0 ft3 (28.3) | 1" (25mm) | 48 | 60° | 29 x 19 x 39 (737 x 483 x 991) | SP-10 | H-4293 | H-4288.2 |
