Specifications
| Capacity: | 90g |
|---|---|
| Readability: | 0.01% / 0.001g |
| Moisture Range: | 0.01% to 100% (0.01% to 1000% in regain mode) |
| Recommended MC%: | 0.5% to 100% |
| Minimum Start Weight: | 0.5 g |
| Temp Range: | 40-200°C (1°C incremental) |
| Display Type: | 4.3” capacitive touch screen |
| Heating Element: | Carbon Fiber |
| Drying Programs: | Standard, Fast, Ramp, Step |
| Method Library: | 20 |
| Result Storage: | 200 |
| Switch-off Criteria: | 5 automatic, timed (1 - 480 mins), manual, free |
| ID Management: | Sample Name (Free Defined), Sample ID (Free Defined) and Batch ID (Free Defined) |
| Status Light: | Multi-color status light |
| Operation Instruction: | • Live drying curve • Live drying curve |
| Display Results: | MC%, DC%, RG%, time, temperature, weight, method name., drying curve and statistics |
| Language: | English, French, German, Italian, Spanish, Portuguese, Chinese, Korean, Japanese, Polish, Turkish |
| Adjustment: | • Temperature adjustment (100°C, 160°C) • External weight adjustment (50g) |
| Output: | RS232, USB host, USB device |
| Power: | 120 VAC 50/60 Hz |
| Operating Temperature Range: | 10-40°C |
| Pan Size: | 3.5 inch / 90mm |
| Dimensions (W x D x H): | 210x138x352 mm / 8.3"x5.4"x13.9" |
| Net Weight: | 4.3kg / 9.5lb |
| Shipping Weight: | 6.1kg / 13.4lb |
