Accurate temperature control is the foundation of reliable asphalt binder testing. Because the rheological properties of asphalt and bitumen are extremely temperature sensitive, even minor deviations can significantly affect test results.
- Full Kit Includes Software and Training
Fully Automatic Temperature Calibration
Temperature accuracy and stability are critical in asphalt binder testing. Because asphalt properties are highly sensitive to temperature changes, even the smallest deviation can significantly impact measurement results. SmartPave 93 rheometers feature fully automatic temperature calibration and verification routines through RheoCompass™ software, ensuring confidence in every test and eliminating manual calibration steps.
Advanced Peltier Temperature Control
Temperature is the single most influential parameter in rheological testing of asphalt binders and bitumen. The SmartPave 93 incorporates an advanced Peltier heating system with heating elements positioned both above and below the sample, a first in its class.
- Near-zero temperature gradients
- Rapid heating and cooling rates
- Test times reduced by nearly 50%
- Improved repeatability and reproducibility
The enclosed asphalt chamber prevents water from circulating through the sample, providing a completely dry testing environment for enhanced stability and accuracy.
Automatic Tool Recognition with Toolmaster™
Toolmaster™ is a fully contact-free automatic tool recognition and configuration system designed specifically for rheometers used in asphalt and bitumen analysis. As soon as a measuring geometry or temperature control unit is connected, the system is automatically detected and configured. This eliminates manual setup errors, reduces downtime, and improves laboratory productivity.
RheoCompass™ Software for AASHTO & ASTM Compliance
The intuitive RheoCompass™ software is engineered specifically for asphalt laboratories. It includes predefined, step-by-step testing procedures that align with international asphalt binder specifications, making compliance simple and consistent.
- Parallel-plate systems
- Cone-plate systems
- Concentric-cylinder systems
This flexibility ensures the optimal geometry for your specific application.
QuickConnect – Fast, One-Handed System Changes
The QuickConnect coupling system enables rapid, one-handed installation and removal of measuring systems. With no screw mechanisms required, switching geometries is fast, secure, and effortless, maximizing lab productivity.
TruRay™ – Clear Visibility for Accurate Setup
TruRay™ integrated illumination provides a clear view of the sample and measuring gap. This ensures precise sample placement and consistent gap settings — critical for accurate rheological measurements of asphalt binders.
