Mixer with 5L (5.3qt) capacity provides automatic program control and auto sand feed with manually-controlled cement and water supply. Different water amounts (100-600 ml) can be freely programmed into the system. Provides software with 4 standard programs installed covering the following standards: ASTM C305, EN 196 -1,3,9; EN 480 and EN 413. Two-speed mixer designed to mix cement mortars and pastes. Mixer features a 5 Liter (5.3qt) stainless steel bowl and ASTM stirrer, and a two-speed motor, which runs at either 140 ±5 rpm or 285 ±10 rpm.
This updated model includes new LED lighting from top to bowl, providing enhanced visibility during operation. It also features a new ergonomic handle for improved user comfort and control.
Features a control panel, which provides fast, easy control in eight languages. Numerous safety features are incorporated in the mixer and include a service program with malfunction messages for the operator, including paddle/planetary speed and time monitoring.
Heavy-duty construction of aluminum and cast iron provides durability and a long service life. The mixer provides a powerful motor for quiet and maintenance-free operation, aided by the use of planetary gears and a toothed, belt drive. The mixing bowl is connected to the mixer by a quick-release clamping system. The distance between the mixing bowl and the stirrer can be easily and accurately be set.
Mixer design conforms to CE standards, featuring a mixing bowl cover, electronic position monitoring of the mixing bowl, an emergency stop switch, and restart protection. Includes stainless steel cabinet.
- H-3854.3F: ASTM 4.73L (5 qt) 220-240V or 110-120V 50/60Hz
- H-3854EN.3F: EN 5L (5.3qt) 220-240V or 110-120V 50/60Hz
Click here to learn more about cement and mortar principles and testing techniques.
