Servo-Hydraulic Universal Testing Machine (25kN)

Servo-Hydraulic Universal Testing Machine (25kN)

Product Options

  Part Number & Name Price QTY
Servo-Hydraulic Universal Testing Machine (25kN)HA-5200.7F
Servo-Hydraulic Universal Testing Machine (25kN)
$89,950.00
Add to Cart

Servo-Hydraulic Universal Testing Machine (25kN)

The Servo-Hydraulic Universal Testing Machine (CS-UTM-HYD) is a well-designed, inexpensive machine specifically developed for the testing of materials used in pavement construction.

A motorized, adjustable crosshead reduces the time between test setups. The programmable temperature cabinet provides the possibility to perform frequency/temperature sweeps. Accurate waveforms are digitally generated and applied by the actuator producing repeatable conditions that are simulative of those created by moving or static vehicles. The actuator is double-acting allowing both compressive and tensile forces to be applied. Various systems are available for the measurement of the modulus of unbound materials.

Features:

  • Designed to perform a range of tests on asphaltic paving materials, sub-grade soils and granular sub-base materials
  • Double acting fatigue rated hydraulic actuator with integral stroke transducer
  • Utilizes Star servo valve with “Sapphire Technology”
  • Motorized adjustable lower crosshead with automatic hydraulic frame clamping
  • Integral programmable temperature controlled cabinet
  • Accessories available to perform a range of standard and non-standard test methods

Software:

  • User friendly, intuitive and reliable Windows® software developed using LabVIEW™
  • Standard test software available to meet specific EN, ASTM and AASHTO test methods
  • Universal test software for the development of test methods using static, sinusoidal, haversine, square, triangular with user selected frequencies and data collection rates
  • Stored test data can be imported into a spreadsheet package to be analysed by the user
  • Utilities are included for transducer check, diagnostic routines and calibration
The Servo-Hydraulic Universal Testing Machine (25kN) supports the following standards: ASTM D7369, ASTM D4123, ASTM D3497, ASTM D7313, AASHTO TP31, AASHTO TP62, AASHTO TP79, AASHTO T307, EN 12697 Annex A, B, C, D and E, EN 12697-44 SCB, NCHRP 1-28A.19. 9-29

Accessories

  Part Number & Name Price QTY
cDAC Advanced Data Acquisition System HA-5105
cDAC Advanced Data Acquisition System
Call
Add to Cart

Standards

Standards
ASTM D7369
ASTM D4123
ASTM D3497
ASTM D7313
AASHTO TP31
AASHTO TP62
AASHTO TP79
AASHTO T307
EN 12697 Annex A
B
C
D and E
EN 12697-44 SCB
NCHRP 1-28A.19. 9-29
